Let Nverse Studios assist you with your reverse engineering needs. In our lab or at your site, we can extract the digital shape of physical objects and provide that data to you to use in reproduction, study, analyzation, inspection or use the data in other downstream applications. Generating a NURBS surface model is great for creating an exact digital representation of the 3D scan data of a model, but is limited by modifications that can be made to the scan. Nverse Studios can create a Parametric CAD model from 3D scan data that can identify and define various parameters.

Nverse Studios uses the latest state-of-the-art, RapidForm Inc technology XOR / XOS suite of products. The modeling team can translate point cloud data into accurate, high quality parametric models for CAD and CAM applications. The data formats are many that can be produced contact us today and find the right solution to your needs.

Reverse engineering 3D scan data to a parametric CAD model can be useful for a variety of applications including benchmarking, creating a CAD model for a part that lacks documentation, or for creating a CAD model from a clay model. Once the 3D scan data of a part has been modeled in RapidformXO Redesign the model can be exported and modified in a variety of CAD applications including SolidWorks, Pro/Engineer and UG NX. Various outputs of the digital data can be provided to our customers. Please contact us and let us help you decide which is the right solution for you!
